Locker Android Quick Start Guide

Created: Modified: Documentation

Imprivata Mobile Access Management 6.0 and later supports Android mobile devices. Customers can benefit from the power of the MAM platform to help manage their fleet for devices. New and existing customers can utilize the identity and asset management features of MAM, all in one console. The familiar tap and go workflows allow users to check out Android devices

This document will guide you through the steps of setting up the Imprivata Locker Android app and enabling a Check Out and Check In Workflow for your Android device For more information on Locker Android, see this article.

Before You Begin

This guide assumes the following:

  • MAM Server 6.0 and later
  • MAM Launchpad 6.0 and later
  • Imprivata Locker Android app 1.0 and later
  • MAM licensing for Check Out
  • MAM is configured with Imprivata Enterprise Access Management (formerly Imprivata OneSign). For more information, see integrating with Imprivata OneSign.
System Requirements
ItemSupport
Operating system
Android OSAndroid 9 or later
Devices
Cisco devicesCP 860
GoogleGoogle Pixel 7
Google Pixel 7a
Google Pixel 8
Google Pixel 8 Pro
Honeywell devicesCT30 (non-healthcare)
Samsung devicesSamsung S22
Samsung A14
Samsung A15 5G
Samsung xCover 6 Pro
Spectralink devicesVersity 95
Versity 96
Versity 97XX
Zebra devicesZebra TC5 series - TC52, TC57
Zebra TC2 series - TC21, TC26
Zebra HC50
Zebra ET40 tablet
Mobile browsersMAM supports clearing browser cache as part of Check In action:
- Google Chrome
- Microsoft Edge
Device settings and permissionsThe Imprivata Locker app for Android devices requires the following device settings and permissions:
- Draw over (overlay) other apps.
- Accessibility Service.
MDMsAndroid devices must be enrolled in an MDM system:
- Workspace ONE (AirWatch)
- Microsoft Intune
- SOTI MobiControl
Getting Started
Step 1 – Obtain the Locker App for Android from Google Play

For more information on obtaining the Locker app, see the Locker App article.

Step 2 – Assign and Register Locker Android with Your MDM

This is an important and foundational step to ensure that MAM, the Locker app, and your MDM are communicating with each other correctly. See Imprivata Locker Android Registration.

Step 3 – Create Workflows

Workflows are collections of settings and assets to deploy to devices. A Workflow may contain several types of actions and can be deployed to a connected device either manually (On-Demand) or automatically (Rule Based, on connect, which can be enabled via the Automation tab). See the Create & Edit Workflows article.

Step 3a – Create a Check In Workflow

For more information, see Check In Device Actions.

Step 3b – Create a Check Out Workflow

For more information, see Basic Check out Workflow – Android.

Step 4 – Automate the Workflows

After you create Check In and Check Out Workflows, set up your automation rules to deploy them to your devices.  For more information, see Configure Basic Checkout Automation.

Wrapping up

At the end of this you’ll be able to successfully check out and check in your Android device. To learn more about what else you can do, such as SSO for Epic Rover, see our documentation.
